25W LED Emergency Backup Driver - Constant Power, 100-277V AC Input, 170V DC Output - Ideal for Commercial & Residential Emergency Lighting

Product Overview

The Emergency Backup Driver - 25W Constant Power is a reliable backup solution for LED Linear High Bay Lights, providing up to 90 minutes of emergency power in case of outages. It supports 100-277V AC input and outputs 170V DC, with the capability to power LED light fixture under 25W or larger LED light fixtures (up to 200W)  with 0-10V dimming at 25W during emergencies.

It can evenly distribute to multiple fixtures when combined wattage does not exceed max load (200 Watts). 0-10V dimming capability is required for fixtures exceeding 25W.

The driver comes with certifications for UL 924, CSA C22.2, FCC, IP44, and CA Title 20 compliant (ECE), ensuring high-quality standards. Backed by a 5-year warranty, it offers durability and peace of mind for commercial and industrial settings.

Its integrated Li-Ion battery simplifies installation by eliminating the need for extra components. Ideal for various applications such as linear lights, low/mid bay lighting, recessed downlights, it’s easy to install and budget-friendly, making it a contractor favorite.

Luminaire Lumen Output Guideline During Emergency Operation:

To determine the lumen output during emergency operation, follow these steps:

1. Fixture Efficacy: Check the luminaire's efficacy under normal AC operation, typically provided by the luminaire vendor.
2. Lumen Calculation: Multiply the fixture’s lumens per watt (LM/W) by the rated emergency output power (25W for this driver).

Here are some suggested Konlite LED high bay lights from our collection and their performance during emergency operation:

1. • Efficacy: 140 LM/W
   • Emergency Output: 25W x 140 LM/W = 3,500 lumens

2. • Efficacy: 156 LM/W

   • Emergency Output: 25W x 156 LM/W = 3,900 lumens

For more technical details, check the LED emergency driver wiring diagram and specifications in the Downloads section.
