Product Overview
The 40W Constant Power Emergency Backup Driver is a reliable backup solution for LED Linear High Bay Lights, providing up to 90 minutes of emergency power in case of outages. It supports 100-277V AC input and outputs 170V DC, with the capability to power LED light fixture under 25W or larger LED light fixtures (up to 320W) with 0-10V dimming at 40W during emergencies.
It can evenly distribute to multiple fixtures when combined wattage does not exceed max load (320 Watts). 0-10V dimming capability is required for fixtures exceeding 40W.
The driver comes with certifications for UL 924, CSA C22.2, FCC, IP44, and CA Title 20 compliant (ECE), ensuring high-quality standards. Backed by a 5-year warranty, it offers durability and peace of mind for commercial and industrial settings.
Its integrated Li-Ion battery simplifies installation by eliminating the need for extra components. Ideal for various applications such as linear lights, low/mid bay lighting, recessed downlights, it’s easy to install and budget-friendly, making it a contractor favorite.
Luminaire Lumen Output Guideline During Emergency Operation:
To determine the lumen output during emergency operation, follow these steps:
- Fixture Efficacy: Check the luminaire's efficacy under normal AC operation, typically provided by the luminaire vendor.
- Lumen Calculation: Multiply the fixture’s lumens per watt (LM/W) by the rated emergency output power (40W for this driver).
Here are some suggested Konlite LED high bay lights from our collection and their performance during emergency operation:
- Efficacy: 140 LM/W
- Emergency Output: 40W x 140 LM/W = 5,600 lumens
For more technical details, check the LED emergency driver wiring diagram and specifications in the Downloads section.
Applications
| •Warehouses | •Workshops |
| •Convention Centers | •Low Bays |
| •Storage Facilities | •Distribution Centers |
| •Factories | •Supermarkets |
| •Retail | •Gymnasiums |
